Description
The automatically operating process refractometers IPR Basic 2 measure the refractive index continuously and thus, the concentration of a binary or quasi-binary liquid mixture. The measurement is independent of light intensity from the light emitting diode (LED) and is free of signal drift, granting high precision and better process control. Colour, turbidity, undissolved particles or gas bubbles do not affect the measurement. You can choice from 4 measuring ranges.
The IPR Basic 2 is a stand alone process sensor, which does not require an external electronic unit. Its special design and electronic configuration makes it highly flexible and very easy to operate. The programming with a Windows software is also very easy. The measuring values are shown on the integrated, iluminated display. Optional a Data Logger and a Universal Controller are available.
The stainless steel measuring head is:
- IP69K protection class tested by TÜV!
- resistant against chemicals,
- suiting food regulations and
- CIP conform (pipe pig use possible).
The IPR measuring head can be installed in pipes, reactor vessels, mixing tanks, kettles, boiling pans and evaporators, using different weld-in flanges.
